观察 OceanBase 数据库创建索引进度
更新时间：2025-07-25 08:46
分享
适用版本：V2.2.x、V3.1.x、V3.2.x内容类型：How-to
在 OceanBase 数据库中，创建索引是一个多阶段的过程。了解索引创建的不同阶段以及如何观察每个阶段的进度对于数据库管理和性能优化至关重要。本文介绍如何观察 OceanBase 数据库创建索引的进度。
索引创建的阶段
OceanBase 数据库创建索引的过程主要可以分为以下几个阶段：
准备阶段：生成索引表的元数据信息，索引表设置为只写状态；等待之前未向索引表插入数据的事务结束，获取构建快照点。
构建阶段：基于获取的快照点扫描主表数据，并将数据写入索引表基线 SSTable 中，同时将增量事务产生的数据写入到 MemTable 中，并完成基线补全，即将快照点后的 DML 操作同步到索引中。
拷贝阶段：索引构建在单副本上完成后，会通过一致性算法将数据同步到索引表的多个副本中。
收尾阶段：进行数据校验，对于唯一索引还需要进行唯一性校验。完成后索引表设置成可读写状态，否则设置为不可用状态。
观察全局索引创建过程
全局索引主要依靠观察 __all_index_build_stat 信息表定位创建到哪个阶段。
该表的 status 列值对应如下：
0 = invalid，创建本地索引时观察该值为 0 1 = 单副本构建 2 = 多副本拷贝 3 = 校验唯一性 4 = 校验和比对 5 = 设置索引生效 6 = 构建索引失败 7 = 构建索引完成
以下示例基于 OceanBase 数据库 V2.2.77 版本，MySQL 租户。
准备阶段。
a. 查看建表语句。
mysql> show create table t1; +-------+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ | Table | Create Table | +-------+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+ | t1 | CREATE TABLE `t1` ( `id` int(11) NOT NULL AUTO_INCREMENT, `k` int(11) NOT NULL DEFAULT '0', `c` char(120) NOT NULL DEFAULT '', `pad` char(60) NOT NULL DEFAULT '', PRIMARY KEY (`id`, `k`)) AUTO_INCREMENT = 12000001 DEFAULT CHARSET = utf8mb4 ROW_FORMAT = DYNAMIC COMPRESSION = 'zstd_1.0' REPLICA_NUM = 3 BLOCK_SIZE = 16384 USE_BLOOM_FILTER = FALSE TABLET_SIZE = 134217728 PCTFREE = 0 partition by hash(k) (partition p0, partition p1, partition p2, partition p3, partition p4) | +-------+-------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+b. 执行建索引语句。
mysql> create index idx_pad on t1(pad) global;c. 在等待事务结束时，查询 __all_index_build_stat 表 status 列为 1，快照点 snapshot 为 0。
mysql> select * from __all_index_build_stat;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | 2022-04-05 19:19:25.503550 | 2022-04-05 19:19:25.503550 | 1014 | 1114904790615059 | 1114904790615064 | 1 | 0 | 1649157565414240 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+构建阶段。
a. 观察 __all_index_build_stat，status 为 1，已获取快照点 snapshot。
mysql> select * from __all_index_build_stat;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+ | 2022-04-05 19:19:25.503550 | 2022-04-05 19:19:47.551521 | 1014 | 1114904790615059 | 1114904790615064 | 1 | 1649157587510214 | 1649157565414240 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+b. 观察 __all_virtual_table_mgr，已完成 MemTable 创建（table_type=0）。
mysql> select * from __all_virtual_table_mgr where index_id in (select index_table_id from __all_index_build_stat);输出结果如下：
+-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+------+-----------+-----+-----------+-----------+ | svr_ip | svr_port | tenant_id | table_type | table_id | partition_id | index_id | base_version | multi_version_start | snapshot_version | version | logical_data_version | size | is_active | ref | write_ref | trx_count | +-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+------+-----------+-----+-----------+-----------+ | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | +-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+------+-----------+-----+-----------+-----------+c. 观察 __all_virtual_sys_task_status，每个分区都有一个 create index 任务。
mysql> select * from __all_virtual_sys_task_status;输出结果如下：
+----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | start_time | task_type | task_id | svr_ip | svr_port | tenant_id | comment | is_cancel | +----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | 2022-04-05 19:19:48.632648 | create index | YB420B973EA3-0005D1DBCF659889 | xx.xx.xx.xx | 2882 | 1014 | build index task, tenant_id=1014, task_id={ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:0, task_cnt:5} | 0 | | 2022-04-05 19:19:48.633941 | create index | YB420B973EA3-0005D1DBCF65988A | xx.xx.xx.xx | 2882 | 1014 | build index task, tenant_id=1014, task_id={ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:1, task_cnt:5} | 0 | | 2022-04-05 19:19:48.635211 | create index | YB420B973EA3-0005D1DBCF65988B | xx.xx.xx.xx | 2882 | 1014 | build index task, tenant_id=1014, task_id={ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:2, task_cnt:5} | 0 | | 2022-04-05 19:19:48.636490 | create index | YB420B973EA3-0005D1DBCF65988C | xx.xx.xx.xx | 2882 | 1014 | build index task, tenant_id=1014, task_id={ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:3, task_cnt:5} | 0 | | 2022-04-05 19:19:48.637767 | create index | YB420B973EA3-0005D1DBCF65988D | xx.xx.xx.xx | 2882 | 1014 | build index task, tenant_id=1014, task_id={ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:4, task_cnt:5} | 0 | +----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+d. 观察 __all_virtual_rebalance_task_stat，每个分区都有一个 SQL_BACKGROUND_DIST_TASK 任务。
mysql> select * from __all_virtual_rebalance_task_stat;输出结果如下：
+-----------+------------------+--------------+-----------------+-----------+-------------+------------------+-----------+--------------+--------------------------+--------------+-----------+--------------+----------------+ | tenant_id | table_id | partition_id | partition_count | source | data_source | destination | offline | is_replicate | task_type | is_scheduled | is_manual | waiting_time | executing_time | +-----------+------------------+--------------+-----------------+-----------+-------------+------------------+-----------+--------------+--------------------------+--------------+-----------+--------------+----------------+ | 1014 | 1114904790615059 | 0 | 0 | 0.0.0.0:0 | 0.0.0.0:0 | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | SQL_BACKGROUND_DIST_TASK | Yes | No | 56 | 326548 | | 1014 | 1114904790615059 | 1 | 0 | 0.0.0.0:0 | 0.0.0.0:0 | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | SQL_BACKGROUND_DIST_TASK | Yes | No | 1374 | 325151 | | 1014 | 1114904790615059 | 2 | 0 | 0.0.0.0:0 | 0.0.0.0:0 | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | SQL_BACKGROUND_DIST_TASK | Yes | No | 2550 | 323916 | | 1014 | 1114904790615059 | 3 | 0 | 0.0.0.0:0 | 0.0.0.0:0 | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | SQL_BACKGROUND_DIST_TASK | Yes | No | 3793 | 322623 | | 1014 | 1114904790615059 | 4 | 0 | 0.0.0.0:0 | 0.0.0.0:0 | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | SQL_BACKGROUND_DIST_TASK | Yes | No | 5025 | 321342 | +-----------+------------------+--------------+-----------------+-----------+-------------+------------------+-----------+--------------+--------------------------+--------------+-----------+--------------+----------------+e. 观察 __all_index_checksum，暂无 checksum 信息。
mysql> select count(*) from __all_index_checksum where gmt_create>'2022-04-05 19:19:00' and tenant_id=1014;输出结果如下：
+----------+ | count(*) | +----------+ | 0 | +----------+f. 观察 __all_virtual_sys_task_status，有一个 create index 任务。
mysql> select * from __all_virtual_sys_task_status;输出结果如下：
+----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | start_time | task_type | task_id | svr_ip | svr_port | tenant_id | comment | is_cancel | +----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | 2022-04-05 19:19:50.958727 | create index | YB420B973EA3-0005D1DBCF65988E | xx.xx.xx.xx | 2882 | 1014 | build index task, tenant_id=1014, task_id={ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:3}, task_id:0, task_cnt:1} | 0 | +----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+g. 观察 __all_virtual_rebalance_task_stat，有一个 SQL_BACKGROUND_DIST_TASK 任务。
mysql> select * from __all_virtual_rebalance_task_stat;输出结果如下：
+-----------+------------------+--------------+-----------------+-----------+-------------+------------------+-----------+--------------+--------------------------+--------------+-----------+--------------+----------------+ | tenant_id | table_id | partition_id | partition_count | source | data_source | destination | offline | is_replicate | task_type | is_scheduled | is_manual | waiting_time | executing_time | +-----------+------------------+--------------+-----------------+-----------+-------------+------------------+-----------+--------------+--------------------------+--------------+-----------+--------------+----------------+ | 1014 | 1114904790615064 | 0 | 0 | 0.0.0.0:0 | 0.0.0.0:0 | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | SQL_BACKGROUND_DIST_TASK | Yes | No | 41 | 3646335 | +-----------+------------------+--------------+-----------------+-----------+-------------+------------------+-----------+--------------+--------------------------+--------------+-----------+--------------+----------------+h. 观察 __all_index_checksum，发现有 5 个分区的索引列（pad）、主键列（id、k）信息，5x3=15。
mysql> select count(*) from __all_index_checksum where gmt_create>'2022-04-05 19:19:00' and tenant_id=1014;输出结果如下：
+----------+ | count(*) | +----------+ | 15 | +----------+i. 观察 __all_virtual_sys_task_status，暂无任务信息。
mysql> select * from __all_virtual_sys_task_status; Empty set (0.01 sec)j. 观察 __all_virtual_rebalance_task_stat，暂无任务信息。
mysql> select * from __all_virtual_rebalance_task_stat; Empty set (0.01 sec)k. 观察 __all_index_checksum，发现多出了全局索引表的 checksum 信息。
mysql> select count(*) from __all_index_checksum where gmt_create>'2022-04-05 19:19:00' and tenant_id=1014;输出结果如下：
+----------+ | count(*) | +----------+ | 18 | +----------+l. 观察 __all_index_checksum 内容（以下内容为重建索引获取，会存在索引表 id 不一致情况）：
mysql> select * from __all_index_checksum where gmt_create>'2022-04-05 20:10:00' and tenant_id=1014 order by column_id;输出结果如下：
+----------------------------+----------------------------+---------------------+-----------+------------------+--------------+-----------+---------+-------------------+-----------------+ | gmt_create | gmt_modified | execution_id | tenant_id | table_id | partition_id | column_id | task_id | checksum | checksum_method | +----------------------------+----------------------------+---------------------+-----------+------------------+--------------+-----------+---------+-------------------+-----------------+ | 2022-04-05 20:10:45.452655 | 2022-04-05 20:10:45.452655 | 4611686018427387911 | 1014 | 1114904790615059 | 0 | 16 | 0 | 4294189217994805 | 2 | | 2022-04-05 20:10:45.394463 | 2022-04-05 20:10:45.394463 | 4611686018427387911 | 1014 | 1114904790615059 | 1 | 16 | 1 | 4293460459368680 | 2 | | 2022-04-05 20:11:45.061528 | 2022-04-05 20:11:45.061528 | 4611686018427387911 | 1014 | 1114904790615068 | 0 | 16 | 0 | 21474837339484641 | 2 | | 2022-04-05 20:10:45.442407 | 2022-04-05 20:10:45.442407 | 4611686018427387911 | 1014 | 1114904790615059 | 2 | 16 | 2 | 4294471659607893 | 2 | | 2022-04-05 20:10:45.377162 | 2022-04-05 20:10:45.377162 | 4611686018427387911 | 1014 | 1114904790615059 | 4 | 16 | 4 | 4291068240165421 | 2 | | 2022-04-05 20:10:45.391626 | 2022-04-05 20:10:45.391626 | 4611686018427387911 | 1014 | 1114904790615059 | 3 | 16 | 3 | 4301647762347842 | 2 | | 2022-04-05 20:10:45.452655 | 2022-04-05 20:10:45.452655 | 4611686018427387911 | 1014 | 1114904790615059 | 0 | 17 | 0 | 4294529994534407 | 2 | | 2022-04-05 20:11:45.061528 | 2022-04-05 20:11:45.061528 | 4611686018427387911 | 1014 | 1114904790615068 | 0 | 17 | 0 | 21478992387389366 | 2 | | 2022-04-05 20:10:45.377162 | 2022-04-05 20:10:45.377162 | 4611686018427387911 | 1014 | 1114904790615059 | 4 | 17 | 4 | 4295367552394642 | 2 | | 2022-04-05 20:10:45.391626 | 2022-04-05 20:10:45.391626 | 4611686018427387911 | 1014 | 1114904790615059 | 3 | 17 | 3 | 4296764324236270 | 2 | | 2022-04-05 20:10:45.442407 | 2022-04-05 20:10:45.442407 | 4611686018427387911 | 1014 | 1114904790615059 | 2 | 17 | 2 | 4299921221083111 | 2 | | 2022-04-05 20:10:45.394463 | 2022-04-05 20:10:45.394463 | 4611686018427387911 | 1014 | 1114904790615059 | 1 | 17 | 1 | 4292409295140936 | 2 | | 2022-04-05 20:10:45.442407 | 2022-04-05 20:10:45.442407 | 4611686018427387911 | 1014 | 1114904790615059 | 2 | 19 | 2 | 4296268846119605 | 2 | | 2022-04-05 20:10:45.391626 | 2022-04-05 20:10:45.391626 | 4611686018427387911 | 1014 | 1114904790615059 | 3 | 19 | 3 | 4300722872371463 | 2 | | 2022-04-05 20:10:45.394463 | 2022-04-05 20:10:45.394463 | 4611686018427387911 | 1014 | 1114904790615059 | 1 | 19 | 1 | 4289982707443986 | 2 | | 2022-04-05 20:10:45.377162 | 2022-04-05 20:10:45.377162 | 4611686018427387911 | 1014 | 1114904790615059 | 4 | 19 | 4 | 4293685226392460 | 2 | | 2022-04-05 20:10:45.452655 | 2022-04-05 20:10:45.452655 | 4611686018427387911 | 1014 | 1114904790615059 | 0 | 19 | 0 | 4292840718037296 | 2 | | 2022-04-05 20:11:45.061528 | 2022-04-05 20:11:45.061528 | 4611686018427387911 | 1014 | 1114904790615068 | 0 | 19 | 0 | 21473500370364810 | 2 | +----------------------------+----------------------------+---------------------+-----------+------------------+--------------+-----------+---------+-------------------+-----------------+m. 求和 checksum。
mysql> select 4294189217994805+4293460459368680+4294471659607893+4291068240165421+4301647762347842;输出结果如下：
+--------------------------------------------------------------------------------------+ | 4294189217994805+4293460459368680+4294471659607893+4291068240165421+4301647762347842 | +--------------------------------------------------------------------------------------+ | 21474837339484641 | +--------------------------------------------------------------------------------------+拷贝阶段。
a. 观察 __all_index_build_stat，status 为 2，已进入多副本拷贝阶段。
mysql> select * from __all_index_build_stat;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+ | 2022-04-05 19:19:25.503550 | 2022-04-05 19:20:53.331745 | 1014 | 1114904790615059 | 1114904790615064 | 2 | 1649157587510214 | 1649157565414240 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+b. 观察 __all_virtual_table_mgr，发现正在拷贝基线 SSSTable（table_type=1）。
mysql> select * from __all_virtual_table_mgr where index_id in (select index_table_id from __all_index_build_stat);输出结果如下：
+-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+-----------+-----------+-----+-----------+-----------+ | svr_ip | svr_port | tenant_id | table_type | table_id | partition_id | index_id | base_version | multi_version_start | snapshot_version | version | logical_data_version | size | is_active | ref | write_ref | trx_count | +-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+-----------+-----------+-----+-----------+-----------+ | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615064 | 0 | 1114904790615064 | 0 | 1649157587510214 | 1649157587510214 | 298 | 298 | 293289439 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615064 | 0 | 1114904790615064 | 0 | 1649157587510214 | 1649157587510214 | 298 | 298 | 293289439 | 0 | 3 | 0 | 0 | +-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+-----------+-----------+-----+-----------+-----------+c. 观察 __all_virtual_sys_task_status，发现 migration 任务。
mysql> select * from __all_virtual_sys_task_status;输出结果如下：
+----------------------------+----------------------------+-------------------------------+-------------+----------+-----------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | start_time | task_type | task_id | svr_ip | svr_port | tenant_id | comment | is_cancel | +----------------------------+----------------------------+-------------------------------+-------------+----------+-----------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | 2022-04-05 19:20:56.134953 | group partition migration | YB420B277B81-0005C4F9E6B7E579 | xx.xx.xx.xx | 2882 | 1014 | group partition migration executor: group_task_id=YB420B277B81-0005C4F9E6B7E579 partition_count=1 partition_id=0 key={tid:1114904790615064, partition_id:0, part_cnt:0}, op_type=COPY_GLOBAL_INDEX_OP, src="xx.xx.xx.xx:xxxx", dest="xx.xx.xx.xx:xxxx", | 0 | | 2022-04-05 19:20:56.137597 | single partition migration | YB420B277B81-0005C4F9C3F84711 | xx.xx.xx.xx | 2882 | 1014 | single partition migration: group_task_id=YB420B277B81-0005C4F9E6B7E579 key={tid:1114904790615064, partition_id:0, part_cnt:0}, op_type=COPY_GLOBAL_INDEX_OP, src="xx.xx.xx.xx:xxxx", dest="xx.xx.xx.xx:xxxx",dest_memstore_percent=100 | 0 | +----------------------------+----------------------------+-------------------------------+-------------+----------+-----------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+d. 观察 __all_virtual_rebalance_task_stat，发现 COPY_SSTABLE 任务。
mysql> select * from __all_virtual_rebalance_task_stat;输出结果如下：
+-----------+------------------+--------------+-----------------+------------------+------------------+------------------+-----------+--------------+--------------+--------------+-----------+--------------+----------------+ | tenant_id | table_id | partition_id | partition_count | source | data_source | destination | offline | is_replicate | task_type | is_scheduled | is_manual | waiting_time | executing_time | +-----------+------------------+--------------+-----------------+------------------+------------------+------------------+-----------+--------------+--------------+--------------+-----------+--------------+----------------+ | 1014 | 1114904790615064 | 0 | 0 | xx.xx.xx.xx:xxxx | xx.xx.xx.xx:xxxx | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | COPY_SSTABLE | Yes | No | 57 | 452611 | +-----------+------------------+--------------+-----------------+------------------+------------------+------------------+-----------+--------------+--------------+--------------+-----------+--------------+----------------+收尾阶段。
a. 观察 __all_index_build_stat，status 为 5，设置索引表生效。
mysql> select * from __all_index_build_stat;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+ | 2022-04-05 19:19:25.503550 | 2022-04-05 19:20:58.114574 | 1014 | 1114904790615059 | 1114904790615064 | 5 | 1649157587510214 | 1649157565414240 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+------------------+------------------+b. 观察 __all_virtual_table_mgr，发现基线 SSTable（table_type=1）已补齐。
mysql> select * from __all_virtual_table_mgr where index_id in (select index_table_id from __all_index_build_stat);输出结果如下：
+-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+-----------+-----------+-----+-----------+-----------+ | svr_ip | svr_port | tenant_id | table_type | table_id | partition_id | index_id | base_version | multi_version_start | snapshot_version | version | logical_data_version | size | is_active | ref | write_ref | trx_count | +-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+-----------+-----------+-----+-----------+-----------+ | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615064 | 0 | 1114904790615064 | 0 | 1649157587510214 | 1649157587510214 | 298 | 298 | 293289439 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 0 | 1114904790615064 | 0 | 1114904790615064 | 1649095210272570 | 1649095210272570 | 9223372036854775807 | 0 | 0 | 0 | 1 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615064 | 0 | 1114904790615064 | 0 | 1649157587510214 | 1649157587510214 | 298 | 298 | 293289439 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615064 | 0 | 1114904790615064 | 0 | 1649157587510214 | 1649157587510214 | 298 | 298 | 293289439 | 0 | 2 | 0 | 0 | +-------------+----------+-----------+------------+------------------+--------------+------------------+------------------+---------------------+---------------------+---------+----------------------+-----------+-----------+-----+-----------+-----------+补充：查询 select index_status from __all_virtual_table where table_id= 索引表 id，为 2 说明索引表构建成功。
观察历史任务表，可供参考。
a. 观察 __all_rootservice_event_history：查看 start_sql_bkgd_task、finish_sql_bkgd_task 以及任务中的 tid（主表 or 索引表），可大致观察单副本构建进度。
mysql> select * from __all_rootservice_event_history where gmt_create>'2022-04-05 19:19:00';输出结果如下：
+----------------------------+----------------------+----------------------+-----------+--------------------------------------------------------------------------------+---------------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+-------------------------------------------+-----------+-------------------------------------------+-------------------+------------------+------------+-------------+-------------+ | gmt_create | module | event | name1 | value1 | name2 | value2 | name3 | value3 | name4 | value4 | name5 | value5 | name6 | value6 | extra_info | rs_svr_ip | rs_svr_port | +----------------------------+----------------------+----------------------+-----------+--------------------------------------------------------------------------------+---------------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+-------------------------------------------+-----------+-------------------------------------------+-------------------+------------------+------------+-------------+-------------+ | 2022-04-05 19:19:47.546665 | snapshot | acquire_snapshot | ret | 0 | snapshot | {snapshot_type:1, snapshot_ts:1649157587510214, schema_version:1649157565414240, tenant_id:1014, table_id:1114904790615059, comment:null} | rs_addr | "xx.xx.xx.xx:xxxx" | | | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.549426 | snapshot | acquire_snapshot | ret | 0 | snapshot | {snapshot_type:1, snapshot_ts:1649157587510214, schema_version:1649157565414240, tenant_id:1014, table_id:1114904790615064, comment:null} | index_table_id | 1114904790615064 | rs_addr | "xx.xx.xx.xx:xxxx" | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.584546 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:0, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.585866 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:1, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.586730 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:0, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 916 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.587137 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:2, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.588387 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:3, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.588633 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:1, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 1537 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.589117 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:2, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 769 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.589639 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:4, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.591192 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:3, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 1595 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:47.592329 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:4, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 1488 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:48.631890 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:0, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:48.633260 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:1, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:48.634501 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:2, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:48.635803 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:3, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:48.637090 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:4, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:50.831480 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:3, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 2194432 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:50.836931 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:0, task_cnt:5} | destination | xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 2203721 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:50.847703 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:1, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 2213246 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:50.879175 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:4, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 2240848 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:50.947911 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:4}, task_id:2, task_cnt:5} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 2312151 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:19:50.958004 | balancer | start_sql_bkgd_task | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:3}, task_id:0, task_cnt:1} | destination | "xx.xx.xx.xx:xxxx" | comment | background executing sql distributed task | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:53.314887 | balancer | finish_sql_bkgd_task | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | task_id | {ob_job_id:{ob_execution_id:{server:"0.0.0.1:1", execution_id:4611686018427387907, hash:13208655902673732501}, job_id:3}, task_id:0, task_cnt:1} | destination | "xx.xx.xx.xx:xxxx" | result | 0 | comment | background executing sql distributed task | elapsed | 62355601 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:53.333361 | global_index_builder | switch_state | tenant_id | 1014 | data_table_id | 1114904790615059 | index_table_id | 1114904790615064 | pre_state | 1 | new_state | 2 | snapshot_version | 1649157587510214 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:55.339970 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615064, partition_id:0, part_cnt:0}, data_size:295698432} | destination | {zone:"zone2", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649157655339784, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649157565445376, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | -1 | comment | copy global index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:56.129230 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615064, partition_id:0, part_cnt:0}, data_size:295698432} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649157565445376, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"zone2", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649157655339784, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy global index sstable | elapsed | 787324 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:56.134256 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615064, partition_id:0, part_cnt:0}, data_size:295698432} | destination | {zone:"zone3", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649157656134096, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649157565445376, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | -1 | comment | copy global index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:57.104507 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615064, partition_id:0, part_cnt:0}, data_size:295698432} | source | {server:"xx.xx.xx.xx:2882", timestamp:1649157565445376, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"zone3", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649157656134096, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy global index sstable | elapsed | 969430 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:58.116159 | global_index_builder | switch_state | tenant_id | 1014 | data_table_id | 1114904790615059 | index_table_id | 1114904790615064 | pre_state | 2 | new_state | 5 | snapshot_version | 1649157587510214 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:59.165987 | global_index_builder | switch_state | tenant_id | 1014 | data_table_id | 1114904790615059 | index_table_id | 1114904790615064 | pre_state | 5 | new_state | 7 | snapshot_version | 1649157587510214 | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:59.167676 | snapshot | release_snapshot | ret | 0 | snapshot | {snapshot_type:1, snapshot_ts:1649157587510214, schema_version:1649157565414240, tenant_id:1014, table_id:1114904790615059, comment:null} | rs_addr | "xx.xx.xx.xx:xxxx" | | | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 19:20:59.167852 | snapshot | release_snapshot | ret | 0 | snapshot | {snapshot_type:1, snapshot_ts:1649157587510214, schema_version:1649157565414240, tenant_id:1014, table_id:1114904790615064, comment:null} | rs_addr | "1xx.xx.xx.xx:xxxx" | | | | | | | | xx.xx.xx.xx | 2882 | +----------------------------+----------------------+----------------------+-----------+--------------------------------------------------------------------------------+---------------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+---------------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+-------------------------------------------+-----------+-------------------------------------------+-------------------+------------------+------------+-------------+-------------+
b. 观察 __all_server_event_history。
mysql> select * from __all_server_event_history where gmt_create>'2022-04-05 19:19:00';
输出结果如下：
+----------------------------+-------------+----------+---------+-------------------------+-----------+----------------------------------------------------+----------------+----------------------------------------------------+----------------+----------------------------------------------------------------------------------------------------------------------------------+-------+----------------------------------------------------------------------------------------------------------------------------------+-------+--------+-------+--------+------------+
| gmt_create | svr_ip | svr_port | module | event | name1 | value1 | name2 | value2 | name3 | value3 | name4 | value4 | name5 | value5 | name6 | value6 | extra_info |
+----------------------------+-------------+----------+---------+-------------------------+-----------+----------------------------------------------------+----------------+----------------------------------------------------+----------------+----------------------------------------------------------------------------------------------------------------------------------+-------+----------------------------------------------------------------------------------------------------------------------------------+-------+--------+-------+--------+------------+
| 2022-04-05 19:19:25.466321 | xx.xx.xx.xx | 2882 | ddl | create_partition | ret | 0 | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | update_pt_cost | 6639 | cost | 13282 | ret | 0 | | | |
| 2022-04-05 19:20:56.134474 | xx.xx.xx.xx | 2882 | storage | copy global index begin | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | | NULL | | | | | | | | | |
| 2022-04-05 19:20:56.134957 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649157565445376, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649157656134096, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | |
| 2022-04-05 19:20:57.103292 | xx.xx.xx.xx | 2882 | storage | rebuild_replica success | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | | NULL | | | | | | | | | |
| 2022-04-05 19:21:45.290608 | xx.xx.xx.xx | 2882 | storage | check_partition_table | ret | 0 | dangling_count | 0 | report_count | 569 | | | | | | | |
| 2022-04-05 19:19:25.463570 | xx.xx.xx.xx | 2882 | ddl | create_partition | ret | 0 | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | update_pt_cost | 5530 | cost | 10054 | ret | 0 | | | |
| 2022-04-05 19:20:55.340742 | xx.xx.xx.xx | 2882 | storage | copy global index begin | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | | NULL | | | | | | | | | |
| 2022-04-05 19:20:55.341253 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | src | {server:"1xx.xx.xx.xx:xxxx", timestamp:1649157565445376, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649157655339784, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | |
| 2022-04-05 19:20:56.127546 | xx.xx.xx.xx | 2882 | storage | rebuild_replica success | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | | NULL | | | | | | | | | |
| 2022-04-05 19:19:25.464926 | xx.xx.xx.xx | 2882 | ddl | create_partition | ret | 0 | partition | {tid:1114904790615064, partition_id:0, part_cnt:0} | update_pt_cost | 5212 | cost | 11415 | ret | 0 | | | |
| 2022-04-05 19:20:59.184522 | xx.xx.xx.xx | 2882 | sql | execute_cmd | cmd_type | 23 | sql_text | create index idx_pad on t1(pad) global | return_code | 0 | | | | | | | |
+----------------------------+-------------+----------+---------+-------------------------+-----------+----------------------------------------------------+----------------+----------------------------------------------------+----------------+----------------------------------------------------------------------------------------------------------------------------------+-------+----------------------------------------------------------------------------------------------------------------------------------+-------+--------+-------+--------+------------+
观察本地索引创建过程
本地索引创建过程不能依靠 __all_index_build_stat 信息表定位创建到哪个阶段。
以下示例基于 OceanBase 数据库 V2.2.77 版本，MySQL 租户。
准备阶段。
a. 模拟未提交事务。
mysql> begin;replace into t1 select * from t1 limit 1; Query OK, 0 rows affected (0.01 sec)b. 执行建索引语句。
mysql> create index idx_pad on t1(pad) local;c. 观察信息表，__all_index_build_stat 的 status 为 0，__all_index_wait_transaction_status 为空。
mysql> select * from __all_index_build_stat;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | 2022-04-05 23:58:17.486334 | 2022-04-05 23:58:17.486334 | 1014 | 1114904790615059 | 1114904790615072 | 0 | 0 | 1649174297424768 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+d. 观察 __all_index_wait_transaction_status，存在 partition_id = -1 的记录，说明等待事务结束。
mysql> select * from __all_index_wait_transaction_status where gmt_create>'2022-04-05 23:47:00' and tenant_id=1014; Empty set (0.01 sec)e. rollback 事务后，继续观察信息表，__all_index_wait_transaction_status 出现 partition_id 为 -1 的记录。
mysql> select * from __all_index_wait_transaction_status where gmt_create>'2022-04-05 23:47:00' and tenant_id=1014;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+----------+--------------+-------------+----------+--------------+------------------+----------------+------------------+ | gmt_create | gmt_modified | tenant_id | index_table_id | svr_type | partition_id | svr_ip | svr_port | trans_status | snapshot_version | frozen_version | schema_version | +----------------------------+----------------------------+-----------+------------------+----------+--------------+-------------+----------+--------------+------------------+----------------+------------------+ | 2022-04-05 23:58:27.867381 | 2022-04-05 23:58:27.867381 | 1014 | 1114904790615072 | 1 | 0 | xx.xx.xx.xx | 2882 | 0 | 1649174307808106 | 0 | 1649174297444528 | | 2022-04-05 23:58:35.097475 | 2022-04-05 23:58:35.097475 | 1014 | 1114904790615072 | 1 | 1 | xx.xx.xx.xx | 2882 | 0 | 1649174315093183 | 0 | 1649174297444528 | | 2022-04-05 23:58:35.107291 | 2022-04-05 23:58:35.107291 | 1014 | 1114904790615072 | 1 | 2 | xx.xx.xx.xx | 2882 | 0 | 1649174315093183 | 0 | 1649174297444528 | | 2022-04-05 23:58:35.103601 | 2022-04-05 23:58:35.103601 | 1014 | 1114904790615072 | 1 | 3 | xx.xx.xx.xx | 2882 | 0 | 1649174315093183 | 0 | 1649174297444528 | | 2022-04-05 23:58:35.097778 | 2022-04-05 23:58:35.097778 | 1014 | 1114904790615072 | 1 | 4 | xx.xx.xx.xx | 2882 | 0 | 1649174315093183 | 0 | 1649174297444528 | | 2022-04-05 23:58:35.200669 | 2022-04-05 23:58:35.200669 | 1014 | 1114904790615072 | 2 | -1 | xx.xx.xx.xx | 2882 | 0 | 1649174315095393 | 298 | 1649174297424768 | +----------------------------+----------------------------+-----------+------------------+----------+--------------+-------------+----------+--------------+------------------+----------------+------------------+构建阶段。
a. 观察信息表 __all_index_build_stat 的 status 为 0。
mysql> select * from __all_index_build_stat;+----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | 2022-04-05 23:58:17.486334 | 2022-04-05 23:58:17.486334 | 1014 | 1114904790615059 | 1114904790615072 | 0 | 0 | 1649174297424768 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+b. 观察 __all_index_schedule_task，有记录说明单副本构建任务开始调度了。
mysql> select * from __all_index_schedule_task where gmt_create>'2022-04-05 23:47:00' and tenant_id=1014;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+--------------+-------------+----------+----------------+------------------+ | gmt_create | gmt_modified | tenant_id | index_table_id | partition_id | svr_ip | svr_port | frozen_version | snapshot_version | +----------------------------+----------------------------+-----------+------------------+--------------+-------------+----------+----------------+------------------+ | 2022-04-05 23:58:35.226664 | 2022-04-05 23:58:35.226664 | 1014 | 1114904790615072 | 0 | xx.xx.xx.xx | 2882 | -1 | 1649174315095393 | | 2022-04-05 23:58:35.228261 | 2022-04-05 23:58:35.228261 | 1014 | 1114904790615072 | 1 | xx.xx.xx.xx | 2882 | -1 | 1649174315095393 | | 2022-04-05 23:58:35.207687 | 2022-04-05 23:58:35.207687 | 1014 | 1114904790615072 | 2 | xx.xx.xx.xx | 2882 | -1 | 1649174315095393 | | 2022-04-05 23:58:35.209417 | 2022-04-05 23:58:35.209417 | 1014 | 1114904790615072 | 3 | xx.xx.xx.xx | 2882 | -1 | 1649174315095393 | | 2022-04-05 23:58:35.209959 | 2022-04-05 23:58:35.209959 | 1014 | 1114904790615072 | 4 | xx.xx.xx.xx | 2882 | -1 | 1649174315095393 | +----------------------------+----------------------------+-----------+------------------+--------------+-------------+----------+----------------+------------------+c. 观察 __all_virtual_table_mgr 为空。
mysql> select * from __all_virtual_table_mgr where index_id in (select index_table_id from __all_index_schedule_task where gmt_create>'2022-04-05 23:47:00' and tenant_id = 1014); Empty set (0.35 sec)d. 观察 __all_virtual_long_ops_status，该表展示集群索引构建的进度，此处进度全部为 0。
mysql> select * from __all_virtual_long_ops_status;输出结果如下：
+-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+-------------+--------------+----------------+------------------+------------+---------+ | tenant_id | sid | op_name | target | svr_ip | svr_port | start_time | finish_time | elapsed_time | remaining_time | last_update_time | percentage | message | +-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+-------------+--------------+----------------+------------------+------------+---------+ | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=0 | xx.xx.xx.xx | 2882 | 1649174315237145 | 0 | 10960834 | 0 | 1649174324491774 | 0 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=1 | xx.xx.xx.xx | 2882 | 1649174315238229 | 0 | 10959777 | 0 | 1649174324039482 | 0 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=3 | xx.xx.xx.xx | 2882 | 1649174315220908 | 0 | 10977102 | 0 | 1649174324098036 | 0 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=2 | xx.xx.xx.xx | 2882 | 1649174315220558 | 0 | 10977455 | 0 | 1649174324439691 | 0 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=4 | xx.xx.xx.xx | 2882 | 1649174315221078 | 0 | 10976937 | 0 | 1649174324198304 | 0 | | +-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+-------------+--------------+----------------+------------------+------------+---------+e. 观察 __all_virtual_sys_task_status，每个分区都有一个 create index 任务。
mysql> select * from __all_virtual_sys_task_status;输出结果如下：
+----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------+-----------+ | start_time | task_type | task_id | svr_ip | svr_port | tenant_id | comment | is_cancel | +----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------+-----------+ | 2022-04-05 23:58:35.220484 | create index | YB420B973EA3-0005D1DBCF659B82 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:2, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | | 2022-04-05 23:58:35.220862 | create index | YB420B973EA3-0005D1DBCF659B83 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:3, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | | 2022-04-05 23:58:35.221034 | create index | YB420B973EA3-0005D1DBCF659B84 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:4, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | | 2022-04-05 23:58:35.237091 | create index | YB420B973EA3-0005D1DBCF659B85 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:0, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | | 2022-04-05 23:58:35.238181 | create index | YB420B973EA3-0005D1DBCF659B86 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:1, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | +----------------------------+--------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------+-----------+f. 观察 __all_virtual_rebalance_task_stat，暂无任务信息。
mysql> select * from __all_virtual_rebalance_task_stat; Empty set (0.00 sec)综上 __all_index_schedule_task 有记录，开始进行单副本构建，__all_virtual_table_mgr 为空，因为本地索引和主表共用 MemTable。
拷贝阶段。
a. 观察信息表 __all_index_build_stat 的 status 为 0。
mysql> select * from __all_index_build_stat;输出结果如下：
+----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | gmt_create | gmt_modified | tenant_id | data_table_id | index_table_id | status | snapshot | schema_version | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+ | 2022-04-05 23:58:17.486334 | 2022-04-05 23:58:17.486334 | 1014 | 1114904790615059 | 1114904790615072 | 0 | 0 | 1649174297424768 | +----------------------------+----------------------------+-----------+------------------+------------------+--------+----------+------------------+b. 观察 __all_virtual_table_mgr，出现 table_type=1 的索引表记录说明单副本构建完成，并且可查看副本拷贝情况。
mysql> select * from __all_virtual_table_mgr where index_id in (select index_table_id from __all_index_schedule_task where gmt_create>'2022-04-05 23:47:00' and tenant_id = 1014);输出结果如下：
+-------------+----------+-----------+------------+------------------+--------------+------------------+--------------+---------------------+------------------+---------+----------------------+----------+-----------+-----+-----------+-----------+ | svr_ip | svr_port | tenant_id | table_type | table_id | partition_id | index_id | base_version | multi_version_start | snapshot_version | version | logical_data_version | size | is_active | ref | write_ref | trx_count | +-------------+----------+-----------+------------+------------------+--------------+------------------+--------------+---------------------+------------------+---------+----------------------+----------+-----------+-----+-----------+-----------+ | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 3 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59132328 | 0 | 3 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 1 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59019474 | 0 | 3 | 0 | 0 | +-------------+----------+-----------+------------+------------------+--------------+------------------+--------------+---------------------+------------------+---------+----------------------+----------+-----------+-----+-----------+-----------+c. 观察 __all_virtual_long_ops_status，该表展示集群索引构建的进度，此处进度为二处 50，三处 100。
mysql> select * from __all_virtual_long_ops_status;输出结果如下：
+-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+------------------+--------------+----------------+------------------+------------+---------+ | tenant_id | sid | op_name | target | svr_ip | svr_port | start_time | finish_time | elapsed_time | remaining_time | last_update_time | percentage | message | +-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+------------------+--------------+----------------+------------------+------------+---------+ | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=0 | xx.xx.xx.xx | 2882 | 1649174315237145 | 0 | 14677935 | 14677935 | 1649174326937809 | 50 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=1 | xx.xx.xx.xx | 2882 | 1649174315238229 | 1649174329427219 | 14188990 | 0 | 1649174329427219 | 100 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=3 | xx.xx.xx.xx | 2882 | 1649174315220908 | 1649174329472910 | 14252002 | 0 | 1649174329472910 | 100 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=2 | xx.xx.xx.xx | 2882 | 1649174315220558 | 0 | 14694552 | 14694552 | 1649174326959566 | 50 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=4 | xx.xx.xx.xx | 2882 | 1649174315221078 | 1649174329561240 | 14340162 | 0 | 1649174329561240 | 100 | | +-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+------------------+--------------+----------------+------------------+------------+---------+d. 观察 __all_virtual_sys_task_status，发现 create index 任务和 migration 任务。
mysql> select * from __all_virtual_sys_task_status;输出结果如下：
+----------------------------+----------------------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | start_time | task_type | task_id | svr_ip | svr_port | tenant_id | comment | is_cancel | +----------------------------+----------------------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+ | 2022-04-05 23:58:35.220484 | create index | YB420B973EA3-0005D1DBCF659B82 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:2, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | | 2022-04-05 23:58:35.237091 | create index | YB420B973EA3-0005D1DBCF659B85 | xx.xx.xx.xx | 2882 | 1014 | build index task: key={tid:1114904790615059, partition_id:0, part_cnt:0} index_id=1114904790615072 snapshot_version=1649174315095393 | 0 | | 2022-04-05 23:58:49.886761 | group partition migration | YB420B277B81-0005C4F8FEBAE6B2 | xx.xx.xx.xx | 2882 | 1014 | group partition migration executor: group_task_id=YB420B277B81-0005C4F8FEBAE6B2 partition_count=1 partition_id=3 key={tid:1114904790615059, partition_id:3, part_cnt:0}, op_type=COPY_LOCAL_INDEX_OP, src="xx.xx.xx.xx:xxxx", dest="xx.xx.xx.xx:xxxx", | 0 | | 2022-04-05 23:58:49.888828 | single partition migration | YB420B20364C-0005D52F688C7957 | xx.xx.xx.xx | 2882 | 1014 | single partition migration: group_task_id=YB420B277B81-0005C4F8FEBAE6B2 key={tid:1114904790615059, partition_id:3, part_cnt:0}, op_type=COPY_LOCAL_INDEX_OP, src="xx.xx.xx.xx:xxxx", dest="xx.xx.xx.xx:xxxx",dest_memstore_percent=100 | 0 | | 2022-04-05 23:58:49.914951 | group partition migration | YB420B277B81-0005C4F9E1FBF42E | xx.xx.xx.xx | 2882 | 1014 | group partition migration executor: group_task_id=YB420B277B81-0005C4F9E1FBF42E partition_count=1 partition_id=4 key={tid:1114904790615059, partition_id:4, part_cnt:0}, op_type=COPY_LOCAL_INDEX_OP, src="xx.xx.xx.xx:xxxx", dest="xx.xx.xx.xx:xxxx", | 0 | | 2022-04-05 23:58:49.916544 | single partition migration | YB420B20364C-0005D52F688C7958 | xx.xx.xx.xx | 2882 | 1014 | single partition migration: group_task_id=YB420B277B81-0005C4F9E1FBF42E key={tid:1114904790615059, partition_id:4, part_cnt:0}, op_type=COPY_LOCAL_INDEX_OP, src="xx.xx.xx.xx:xxxx", dest="xx.xx.xx.xx:xxxx",dest_memstore_percent=100 | 0 | +----------------------------+----------------------------+-------------------------------+-------------+----------+-----------+--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------+-----------+e. 观察 __all_virtual_rebalance_task_stat，发现 COPY_SSTABLE 任务。
mysql> select * from __all_virtual_rebalance_task_stat;输出结果如下：
+-----------+------------------+--------------+-----------------+------------------+------------------+------------------+-----------+--------------+--------------+--------------+-----------+--------------+----------------+ | tenant_id | table_id | partition_id | partition_count | source | data_source | destination | offline | is_replicate | task_type | is_scheduled | is_manual | waiting_time | executing_time | +-----------+------------------+--------------+-----------------+------------------+------------------+------------------+-----------+--------------+--------------+--------------+-----------+--------------+----------------+ | 1014 | 1114904790615059 | 3 | 0 | xx.xx.xx.xx:xxxx | xx.xx.xx.xx:xxxx | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | COPY_SSTABLE | Yes | No | 175792 | 49796 | | 1014 | 1114904790615059 | 4 | 0 | xx.xx.xx.xx:xxxx | xx.xx.xx.xx:xxxx | xx.xx.xx.xx:xxxx | 0.0.0.0:0 | No | COPY_SSTABLE | Yes | No | 22679 | 21548 | +-----------+------------------+--------------+-----------------+------------------+------------------+------------------+-----------+--------------+--------------+--------------+-----------+--------------+----------------+综上 __all_virtual_table_mgr 出现 table_type=1 的记录，并且__all_virtual_rebalance_task_stat 出现 COPY_SSTABLE 任务。
收尾阶段。
a. 观察信息表 __all_index_build_stat 的 status 为空。
mysql> select * from __all_index_build_stat; Empty set (0.00 sec)b. 观察 __all_virtual_table_mgr，出现 table_type=1 的索引表记录说明单副本构建完成，并且可查看副本拷贝情况。
mysql> select * from __all_virtual_table_mgr where index_id in (select index_table_id from __all_index_schedule_task where gmt_create>'2022-04-05 23:47:00' and tenant_id = 1014);输出结果如下：
+-------------+----------+-----------+------------+------------------+--------------+------------------+--------------+---------------------+------------------+---------+----------------------+----------+-----------+-----+-----------+-----------+ | svr_ip | svr_port | tenant_id | table_type | table_id | partition_id | index_id | base_version | multi_version_start | snapshot_version | version | logical_data_version | size | is_active | ref | write_ref | trx_count | +-------------+----------+-----------+------------+------------------+--------------+------------------+--------------+---------------------+------------------+---------+----------------------+----------+-----------+-----+-----------+-----------+ | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 4 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59024299 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 2 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59065069 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 2 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59065069 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 1 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59019474 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 1 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59019474 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 0 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59086290 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 2 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59065069 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 4 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59024299 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 3 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59132328 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 3 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59132328 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 3 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59132328 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 0 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59086290 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 1 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59019474 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 0 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59086290 | 0 | 2 | 0 | 0 | | xx.xx.xx.xx | 2882 | 1014 | 1 | 1114904790615059 | 4 | 1114904790615072 | 0 | 1649174315095393 | 1649174315095393 | 298 | 298 | 59024299 | 0 | 2 | 0 | 0 | +-------------+----------+-----------+------------+------------------+--------------+------------------+--------------+---------------------+------------------+---------+----------------------+----------+-----------+-----+-----------+-----------+c. 观察 __all_virtual_long_ops_status，该表展示集群索引构建的进度，此处进度全部为 100。
mysql> select * from __all_virtual_long_ops_status;输出结果如下：
+-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+------------------+--------------+----------------+------------------+------------+---------+ | tenant_id | sid | op_name | target | svr_ip | svr_port | start_time | finish_time | elapsed_time | remaining_time | last_update_time | percentage | message | +-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+------------------+--------------+----------------+------------------+------------+---------+ | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=0 | xx.xx.xx.xx | 2882 | 1649174315237145 | 1649174329929491 | 14692346 | 0 | 1649174329929491 | 100 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=1 | xx.xx.xx.xx | 2882 | 1649174315238229 | 1649174329427219 | 14188990 | 0 | 1649174329427219 | 100 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=3 | xx.xx.xx.xx | 2882 | 1649174315220908 | 1649174329472910 | 14252002 | 0 | 1649174329472910 | 100 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=2 | xx.xx.xx.xx | 2882 | 1649174315220558 | 1649174329965638 | 14745080 | 0 | 1649174329965638 | 100 | | | 1014 | -1 | CREATE INDEX | index_table_id=1114904790615072, partition_id=4 | xx.xx.xx.xx | 2882 | 1649174315221078 | 1649174329561240 | 14340162 | 0 | 1649174329561240 | 100 | | +-----------+-----+--------------+-------------------------------------------------+-------------+----------+------------------+------------------+--------------+----------------+------------------+------------+---------+d. 观察 __all_virtual_sys_task_status，暂无任务信息。
mysql> select * from __all_virtual_sys_task_status; Empty set (0.01 sec)e. 观察 __all_virtual_rebalance_task_stat，暂无任务信息。
mysql> select * from __all_virtual_rebalance_task_stat; Empty set (0.00 sec)综上__all_virtual_table_mgr 副本已全部补齐，__all_virtual_long_ops_status进度全部为100
补充：查询 select index_status from __all_virtual_table where table_id= 索引表 id，为 2 说明索引表构建成功。
观察历史任务表，可供参考。
a. 观察 __all_rootservice_event_history。
mysql> select * from __all_rootservice_event_history where gmt_create>'2022-04-05 23:47:00';输出结果如下：
+----------------------------+----------+---------------------+-----------+------------------------------------------------------------------------+-------------+----------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+----------------------------------------------------------------------------------------------------------------------------------------------------------------+------------------------+---------------------+---------+--------------------------+-------------------+--------+------------+-------------+-------------+ | gmt_create | module | event | name1 | value1 | name2 | value2 | name3 | value3 | name4 | value4 | name5 | value5 | name6 | value6 | extra_info | rs_svr_ip | rs_svr_port | +----------------------------+----------+---------------------+-----------+------------------------------------------------------------------------+-------------+----------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+----------------------------------------------------------------------------------------------------------------------------------------------------------------+------------------------+---------------------+---------+--------------------------+-------------------+--------+------------+-------------+-------------+ | 2022-04-05 23:58:35.198681 | snapshot | acquire_snapshot | ret | 0 | snapshot | {snapshot_type:1, snapshot_ts:1649174315095393, schema_version:1649174297424768, tenant_id:1014, table_id:1114904790615059, comment:null} | index_table_id | 1114904790615072 | rs_addr | "xx.xx.xx.xx:xxxx" | | | | | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.437130 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:1, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329436960, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204840, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.483225 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:3, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329483075, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204991, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.659821 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:1, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204840, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329436960, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 221860 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.659991 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:4, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329570725, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845205017, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.709537 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:3, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204991, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329483075, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 225502 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.709723 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:1, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329664243, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204840, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.885358 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:4, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845205017, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329570725, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 224513 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.885528 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:3, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329709633, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204991, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.913607 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:1, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204840, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329664243, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 201996 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:49.913801 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:4, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329891029, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845205017, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.068782 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:3, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204991, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329709633, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 181354 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.068952 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:0, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329939138, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204803, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.091776 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:4, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845205017, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329891029, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 176090 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.092031 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:2, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329975079, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204879, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.295340 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:0, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204803, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329939138, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 225588 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.296838 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:0, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174330296701, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204803, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.313536 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:2, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204879, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1040, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174329975079, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 220561 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.326999 | balancer | start_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:2, part_cnt:0}, data_size:0} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174330326836, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | data_source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204879, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | index_table_id | 1114904790615072 | comment | copy local index sstable | switchover_epoch_ | 0 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.479907 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:0, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204803, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174330296701, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 181184 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.502998 | balancer | finish_copy_sstable | partition | {pkey:{tid:1114904790615059, partition_id:2, part_cnt:0}, data_size:0} | source | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204879, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | destination | {zone:"", unit_id:1042, member:{server:"xx.xx.xx.xx:xxxx", timestamp:1649174330326836, flag:0, replica_type:0, region:"default_region", memstore_percent:100}} | result | 0 | comment | copy local index sstable | elapsed | 173741 | | xx.xx.xx.xx | 2882 | | 2022-04-05 23:58:50.678176 | snapshot | release_snapshot | ret | 0 | snapshot | {snapshot_type:1, snapshot_ts:1649174315095393, schema_version:1649174297424768, tenant_id:1014, table_id:1114904790615059, comment:null} | rs_addr | "xx.xx.xx.xx:xxxx" | | | | | | | | xx.xx.xx.xx | 2882 | +----------------------------+----------+---------------------+-----------+------------------------------------------------------------------------+-------------+----------------------------------------------------------------------------------------------------------------------------------------------------------------+----------------+----------------------------------------------------------------------------------------------------------------------------------------------------------------+------------------------+---------------------+---------+--------------------------+-------------------+--------+------------+-------------+-------------+b. 观察 __all_server_event_history。
mysql> select * from __all_server_event_history where gmt_create>'2022-04-05 23:47:00';输出结果如下：
+----------------------------+-------------+----------+---------+------------------------+-----------+----------------------------------------------------+----------------+----------------------------------------------------+--------------+--------------------------------------------------------------------------------------------------------------------------------+-------+--------------------------------------------------------------------------------------------------------------------------------+-------+--------+-------+--------+------------+ | gmt_create | svr_ip | svr_port | module | event | name1 | value1 | name2 | value2 | name3 | value3 | name4 | value4 | name5 | value5 | name6 | value6 | extra_info | +----------------------------+-------------+----------+---------+------------------------+-----------+----------------------------------------------------+----------------+----------------------------------------------------+--------------+--------------------------------------------------------------------------------------------------------------------------------+-------+--------------------------------------------------------------------------------------------------------------------------------+-------+--------+-------+--------+------------+ | 2022-04-05 23:58:49.437352 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:49.437840 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204840, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329436960, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:49.483453 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:49.483919 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204991, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329483075, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:49.660276 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:49.660733 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845205017, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329570725, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:50.069158 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:50.069629 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204803, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329939138, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:50.092290 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:50.092835 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204879, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329975079, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:57:15.663885 | xx.xx.xx.xx | 2882 | storage | check_partition_table | ret | 0 | dangling_count | 0 | report_count | 5709 | | | | | | | | | 2022-04-05 23:58:49.710488 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:49.710960 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:1, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204840, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329664243, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:49.886308 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:49.886779 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:3, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204991, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329709633, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:49.914565 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:49.915034 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:4, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845205017, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174329891029, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:50.297613 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:50.298087 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:0, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204803, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174330296701, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:58:50.327861 | xx.xx.xx.xx | 2882 | storage | copy local index begin | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | index_id | 1114904790615072 | | | | | | | | | | | 2022-04-05 23:58:50.328358 | xx.xx.xx.xx | 2882 | ddl | copy_sstable_batch | ret | 0 | partition | {tid:1114904790615059, partition_id:2, part_cnt:0} | src | {server:"xx.xx.xx.xx:xxxx", timestamp:1649155845204879, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | dst | {server:"xx.xx.xx.xx:xxxx", timestamp:1649174330326836, flag:0, replica_type:0, region:"default_region", memstore_percent:100} | | | | | | | 2022-04-05 23:47:48.456067 | xx.xx.xx.xx | 2882 | sql | execute_cmd | cmd_type | 22 | sql_text | alter table t1 drop index idx_pad | return_code | 0 | | | | | | | | | 2022-04-05 23:47:49.381144 | xx.xx.xx.xx | 2882 | sql | execute_cmd | cmd_type | 12 | sql_text | ALTER SYSTEM CHANGE TENANT TENANT_ID = 1 | return_code | 0 | | | | | | | | | 2022-04-05 23:47:49.392310 | xx.xx.xx.xx | 2882 | sql | execute_cmd | cmd_type | 12 | sql_text | ALTER SYSTEM CHANGE TENANT TENANT_ID = 1014 | return_code | 0 | | | | | | | | | 2022-04-05 23:58:50.614277 | xx.xx.xx.xx | 2882 | sql | execute_cmd | cmd_type | 23 | sql_text | create index idx_pad on t1(pad) local | return_code | 0 | | | | | | | | +----------------------------+-------------+----------+---------+------------------------+-----------+----------------------------------------------------+----------------+----------------------------------------------------+--------------+--------------------------------------------------------------------------------------------------------------------------------+-------+--------------------------------------------------------------------------------------------------------------------------------+-------+--------+-------+--------+------------+
总结
诊断任务与事件状态的内部虚拟表。
通过查询内部虚拟表，如 __all_index_build_stat、__all_index_wait_transaction_status、__all_virtual_sys_task_status 等，可以实时监控索引构建的进度和状态。
检查展示正在执行的任务和记录当前正在进行的负载均衡任务的常用的任务与事件诊断用的虚拟表和视图，如 __all_virtual_sys_task_status 和__all_virtual_rebalance_task_stat，以获取相关分区的索引创建任务和分布式任务信息。
通过 __all_virtual_table_mgr 表，可以观察到 MemTable 的创建和 SSTable 的拷贝情况。
历史事件记录表。
- 通过查询历史事件记录表 __all_rootservice_event_history 和__all_server_event_history 内部虚拟表获取的详细信息，包括快照、任务开始/完成、SSTable 复制等事件的记录。
注意
观察索引创建进度是一个动态的过程，需要定期查询系统表以获取最新的状态信息。索引创建的时间取决于多种因素，如表的大小、系统的负载、副本的数量等，当创建索引可能会影响数据库的性能，建议在低峰时间段进行。
适用版本
OceanBase 数据库 V2.x 和 V3.x 版本。
